| Length | 1.8m (6ft), 2.1m (7ft), 2.4m (8ft), 2.7m (9ft), 3.0m (10ft), 3.3m (11ft), 3.6m (12ft), 3.9m (13ft), 4.2m (14ft). Contact us for bespoke / custom Gazebo |
| Width | 1.8m (6ft), 2.1m (7ft), 2.4m (8ft), 2.7m (9ft), 3.0m (10ft), 3.3m (11ft), 3.6m (12ft), 3.9m (13ft), 4.2m (14ft)
Please note the width and depth measurement is from outside post to outside post. The overhang is additional to these measurements. |
| Total Height | 2850mm |
| Post Height | 2320mm |
| Post Size | 150mm x 150mm |
| Corner Brackets | 100mm x 50mm |
|
Roof Overhang at front |
400mm |
| Roof Overhang at side | 400mm |
| Roofing | Katepal Black Shingle |
| Material & Timber | Larch / Spruce Sawn |
| Fixings | All fixings included* |
| Treatment | Each component is fully pressure treated |
| Frame Instructions | Instructions |
| Roofing Instructions | Instructions |
Key Facts:
- Katepal Black Shingle Roof
- Pressure Treated Timber
- 6" x 6" Posts
- 4" x 2" Beams
- Kit Form (Easy Install)
Other Apex Pergolas with Overhang:
Other Katepal Grey Shingle Roof Pergolas:
- Katepal Black Shingle Roof 4 Pitch Apex Pergola
- Katepal Black Shingle Roof Lean-To
Need further advice? Check out our new Pergola Buying Guide.
Please Note: *Feet are not included in accessories but are an optional extra. The pergola comes without a waterproof roof membrane so will not be waterproof. If you would like to make it waterproof, you can simply apply a waterproof roof membrane, available here.
This product is specifically manufactured upon order placement and falls under our "Made-To-Measure" product range. We encourage you to review our Terms and Conditions (Section 2) before placing an order, as they detail guidance regarding orders, returns, and cancellations for "Made-To-Measure" product range.
If the posts are going into ground contact we would always recommend applying Bitumen to the part that is in the ground and sitting just above it. This will help protect timber from rotting.
